学校某教学楼视频监控系统的设计与实现

摘  要

随着社会信息化进程的加速，监控系统在诸多领域，如车内监控、电梯监控等，扮演着越来越重要的角色。传统有线传输模式虽传输速率快，但成本高昂且灵活性受限。随着无线技术的广泛应用，无线传输模式因其成本低、移动便捷及开发潜力大等优势，逐渐成为监控系统的首选。本文设计并实现了一种针对学校某教学楼的视频监控系统，该系统通过CMOS摄像头OV2640采集图像，并利用WIFI技术将图像传输至终端，实现了视频的无线传输及电脑终端对现场的实时监控。

本系统以STM32F4系列微控制器为核心，利用其高速数字相机接口(DCMI)集成OV2640摄像头模组，支持高达200万像素的视频捕捉。同时，系统集成了W5500以太网芯片和NodeMCU WiFi模块，构建了一套基于TCP/IP协议栈的高效视频流传输机制。上位机客户端采用Qt框架开发，提供了良好的人机交互体验。实验结果表明，该系统能够稳定捕捉图像，并通过WIFI流畅地将视频传输至终端显示。

本系统不仅实现了实时视频监控功能，还支持远程截图、云端存储控制以及摄像头云台控制等特性，满足了全方位、多功能的监控需求。

关键词：视频监控系统；学校教学楼；STM32F4系列；OV2640摄像头；WIFI传输

Design and implementation of the video monitoring system in a teaching building of the school

Abstract

With the acceleration of the social informatization process, the monitoring system is playing an increasingly important role in many fields, such as in-car monitoring, elevator monitoring and so on. Although the traditional wired transmission mode has a fast transmission rate, it is costly and has limited flexibility. With the wide application of wireless technology, wireless transmission mode has gradually become the first choice of monitoring system due to its advantages of low cost, convenient mobile mode and great development potential. In this paper, a video surveillance system for a teaching building in the school is designed and realized. The system collects images through the CMOS camera OV2640, and transmits the images to the terminal by using WIFI technology, realizing the wireless video transmission and the real-time monitoring of the computer terminal on the site.

This system takes STM32F4 series microcontrollers as the core, using its OV2640 camera module integrated with high-speed digital camera interface (DCMI), to support up to 2 million pixel video capture. At the same time, the system integrates W5500 Ethernet chip and NodeMCU WiFi module, and builds a set of efficient video flow transmission mechanism based on TCP / IP protocol stack. The host computer client is developed by using the Qt framework, which provides a good human-computer interaction experience. The experimental results show that the system can stably capture images and smoothly transmit video to the terminal display through WIFI.

This system not only realizes the real-time video monitoring function, but also supports remote screenshots, cloud storage control and camera cloud head control and other characteristics, to meet the all-round and multi-functional monitoring

Key words: video surveillance system; school teaching building; STM32F4 series; OV2640 camera; WIFI transmission
