摘要
电力系统是维持社会生活与生产的基本保障，然而随着越来越多的大面积停电时间的发生，传统大规模电网的弊端越来越明显。于是，世界各国都开始关注基于可再生能源的分布式发电技术，同时，微电网概念的提出很好的解决了分布式电源过多接入大电网所产生的不利影响。微电网是从系统的角度定义的，它将分布式电源、负荷、储能单元以及控制装置等结合起来，形成一个独立的系统，并且具有并网运行和孤岛运行两种典型的运行方式：正常情况下，微电网通过公共连接点与外部大电网连接运行，有效的解决了分布式电源大规模的接入问题，并为大电网提供支撑。当大电网产生故障，微电网能够快速断开并过渡到孤岛运行，保证了本地重要负荷的不间断供电。
本文首先介绍了微电网的基本知识，包括微电网的概念、研究应用以及主要组成部分，如开关器件、分布式电源和储能单元等，然后给出三相电压源型逆变器电路拓扑，并分别推导出其在自然坐标系和dq旋转坐标系下的数学模型。接着本文介绍了恒功率PQ控制和下垂控制等的微网控制方法，分析各自适用性和优缺点，并给出理论依据。
在仿真模型的建立和结果分析部分，由于光伏电池在实际生活中的推广应用，本文首先进行光伏电池的建模和仿真分析，并采用MPPT，即最大功率点跟踪，进行光伏电池的输出电压和电流的实时监测。然后针对恒功率PQ控制方法建立孤岛和并网工作模式下的微网模型，通过输出电压以及系统频率波动验证控制方法的准确性。对于Droop控制理论，本文同样建立单电源的孤岛和并网以及分布式电源并网仿真模型，通过系统频率波动以及输出电压验证Droop控制方法的准确性。
综上，本文主要运用Matlab/Simulink软件搭建微电网模型，并分析在微电网孤岛和并网运行模式下控制方法的准确性。
关键词：微电网控制 PQ控制 Droop控制 Matlab/Simulink软件
Abstract
The power system is the basic guarantee to maintain the social life and production. However, as more and more large-scale power outages occur, the disadvantages of the traditional large-scale power grid become more and more obvious. As a result, all countries in the world are beginning to pay attention to distributed generation technology based on renewable energy. At the same time, the concept of microgrid is a good solution to the adverse effect of distributed generation in large power grids. Micro-grid is defined from a system perspective. It combines distributed power, load, energy storage unit and control device to form an independent system. It has two typical operation modes of grid-connected operation and island operation: Normal Under the circumstance, the microgrid is connected with an external large power grid through a public connection point, effectively solving the problem of large-scale access to distributed power and providing support for large power grids. When a large power grid fails, the microgrid can quickly disconnect and transition to island operation, ensuring uninterrupted power supply to important local loads.
This paper first introduces the basic knowledge of microgrid, including the concept of micro-grid, research and application as well as the main components, such as switching devices, distributed power and energy storage unit, and then gives three-phase voltage source inverter circuit topology, And deduces its mathematical model in natural coordinate system and dq rotating coordinate system respectively. Then this paper introduces the constant power PQ control and droop control and other micro-grid control methods, analysis of their respective applicability and advantages and disadvantages, and gives the theoretical basis.
In the simulation model establishment and result analysis part, due to the popularization and application of photovoltaic cells in real life, this paper first modeling and simulation analysis of photovoltaic cells, and using MPPT, the maximum power point tracking, photovoltaic cell output voltage and Then for the constant power PQ control method, the microgrid model under the islanding and grid connection working mode is established, and the accuracy of the control method is verified by the output voltage and the system frequency fluctuation. For Droop control theory, this paper also establishes a single-supply island and grid and distributed power grid-connected simulation model, through the system frequency fluctuations and output voltage verification Droop control method accuracy.
In summary, this paper mainly uses the Matlab / Simulink software to build the micro-grid model and analyzes the accuracy of the control method in the microgrid grid-connected and grid-connected operation mode.
Keywords: Micro-grid control PQ control Droop control Matlab / Simulink software
