摘 要
在现如今能源稀缺的现状下，各个国家都在加速使用太阳能，太阳能路灯的生产广泛用于公共照明领域。然而，传统的太阳能路灯具有控制精度低、防干扰能力低以及成本高的问题。因此，本设计针对以上问题进行了优化设计，使得太阳能路灯系统符合稳定性、实用性、节能环保的要求，其使用具有更广泛的社会价值。其智能路灯控制系统结合光伏电池的特性和蓄电池充电、放电的特性，以AT89C51单片机为核心，主要由蓄电池、LED灯、太阳能电池板、显示器、充电电路、放电电路六个部分构成[1]。同时为了增加太阳能路灯蓄电池的使用寿命，本设计通过软件和硬件相结合的办法，避免了蓄电池出现过充、过放现象，最终通过LED实时显示当前太阳能电池板电压和蓄电池电压，达到利用太阳能实现照明的目的。该系统设计简单、节能环保，消除了能源浪费，实现了可再生资源的有效利用，具有连续的应用价值。
关键词：AT89C51；太阳能；路灯；蓄电池
论文类型：工程设计
Abstract
In the current situation of energy scarcity, various countries are accelerating the use of solar energy, and the production of solar street lights is widely used in the field of public lighting. However, the traditional solar street light has the problems of low control accuracy, low anti-interference ability and high cost. Therefore, this design is optimized for the above problems, so that the solar street light system meets the requirements of stability, practicability, energy saving and environmental protection, and its use has a wider social value. Its intelligent street lamp control system combines the characteristics of photovoltaic cells and the characteristics of battery charging and discharging. It uses AT89C51 single-chip microcomputer as the core and is mainly composed of six parts: battery, LED lamp, solar panel, display, charging circuit, and discharging circuit [1]. At the same time, in order to increase the service life of the solar street lamp battery, this design uses a combination of software and hardware to avoid the battery from overcharging and overdischarging, and finally displays the current solar panel voltage and battery voltage in real time through LEDs to achieve the use of solar energy. The purpose of lighting. The system is simple in design, energy-saving and environmentally friendly, eliminates energy waste, realizes the effective use of renewable resources, and has continuous application value.
Keywords: AT89C51；Solar energy；Street light；Battery
