摘要
转子泵是一种容积泵,通过一对传动比为1的齿轮啮合传动,带动两个转子实现同步反转。在旋转过程中,入口产生真空度,从而吸入待输送的液体。通常也称为非接触式转子泵。其原理是泵体内的两个转子由两个同步齿轮驱动旋转完成吸排水。对于双叶渐开线转子泵的研究,具有十分广阔的应用前景。它不仅适用于石油介质运输,而且在日用化工、石油、医药、食品等行业具有广阔的市场潜力。可输送蜂蜜、牛奶、润滑油等大粘性介质和煤、原油等多相介质。如:润滑油、油脂、原油、沥青、油漆、植物油、蜂蜜、果酱、黄油、牙膏、洗发水、肥皂、油漆、石蜡、尼龙、聚酯、聚乙烯等。
鉴于我国目前对转子泵转子型线设计的理论研究较少,本文着重对转子型线的理论研究。为了提高泵的性能,研究了双叶片渐开线转子泵的基本技术,并对其结构进行了优化。双叶片渐开线转子泵的设计。
转子泵具有工作原理简单、体积小、重量轻、成本低、密封安全、无污染等特点。它不仅适用于石油介质运输,而且在日用化工、石油、制药、食品等行业具有广阔的市场潜力。因此,转子泵在某些场合可以很好地替代螺杆泵和离心泵。
关键词:转子泵;转子型线;结构设计;
Abstract
Rotor pump is a kind of volumetric pump, which drives two rotors to achieve synchronous inversion through a pair of gear meshing transmission with transmission ratio of 1. In the process of rotation, the inlet produces a vacuum, which sucks the liquid to be transported. Usually also known as non-contact rotor pump. The principle is that the two rotors in the pump body are driven by two synchronous gears to complete suction and drainage. The research of double-blade involute rotor pump has very broad application prospects. It is not only suitable for transportation of petroleum medium, but also has broad market potential in daily chemical industry, petroleum, medicine, food and other industries. It can transport large viscous media such as honey, milk, lubricating oil, coal, crude oil and other multi-phase media. Such as: lubricating oil, grease, crude oil, asphalt, paint, vegetable oil, honey, jam, butter, toothpaste, shampoo, soap, paint, paraffin, nylon, polyester, polyethylene and so on.
In view of the fact that there are few theoretical studies on rotor profile design of rotor pump in China, this paper focuses on the theoretical study of rotor profile. In order to improve the performance of the pump, the basic technology of double-blade involute rotor pump was studied and its structure was optimized. Design of double blade involute rotor pump.
Rotor pump has the characteristics of simple working principle, small volume, light weight, low cost, safe sealing and pollution-free. It is not only suitable for petroleum medium transportation, but also has broad market potential in daily chemical, petroleum, pharmaceutical, food and other industries. Therefore, the rotor pump can be a good substitute for screw pump and centrifugal pump in some cases.
Keywords:rotor pump;rotor profile;finite element analysis;
