模拟信号数字无线传输演示系统的设计与实现

摘 要

通信系统分为模拟通信系统和数字通信系统，如果我们在发送端的信息源中包括一个模/数转换装置，在接收端包括一个数/模转换装置，在发送端与接收端之间通过红外作为载波进行通信，则可以实现模拟信号数字无线传输。本文主要从三个方面进行设计与实现：（1）AT89S51单片机对A/D转换器的控制，从而对模拟信号进行抽样、量化、编码后转换为数字信号；（2）单片机对数字信号进行编码与38Khz红外载波调制通过红外线发射；（3）接收机接收到的调制信号经红外接收头进行解调还原数字信号，再经单片机的处理，通过D/A，以及信号的放大，最后再经过低通滤波器还原成模拟信号，从而实现模拟信号数字无线传输演示的全过程。

关键词

模拟信号数字传输；无线传输；红外通信；模数转换；数模转换

Analog Digital Wireless Transmission Communication System

Abstract

Communication system is divided into analog communication systems and digital communication systems, if we send the client's information sources include a A / D converter, the receiver includes a D / A converter, in between the transmitter and the receiver as by infrared carrier to communicate, you can transmit analog signal digital infrared communications. This article mainly focuses on three aspects: (1) AT89S51 microcontroller on the A / D chip to control the analog signal sampling, quantization, encoded into digital signals; (2) single chip digital signal processing and modulation 38KHZ IR through infrared emission; (3) base station receives the first modulated signal by the infrared receiver to demodulate digital signal reduction by the microcontroller processing, through the D / A, and signal amplification and finally through the reduction of low-pass filter into an analog signal, in order to achieve different place communication.

Key words

Analog signal digital transmission ；wireless transmission ；infrared communication ；analog _digital conversion ；digital _ analog conversion
