摘要：水是一切生命过程得以正常进行的生理要素，人是离不开水的。饮水管理对人来说就显得尤为重要，对婴幼儿来说更为重要。孩子身体中的含水量和代谢率较高，肾脏的凋节能力有限，更容易发生水不足或缺乏。本设计采用 AT89C51单片机辅以外围电路作为控制核心完成对水温的监控与控制。杯子外壳部分装有太阳能板充电装置，可对其内部电池充电（一般的USB插口也可对其充电）；保温杯内部通过DS18B20温度传感器来测量水温，杯子外壳设有LED显示屏，显示杯内水温以及设定的温度值，实时显示温度值；人们使用时可以通过温度设定按钮自行设定自己需要的温度，当杯子里面的水温降到我们所设定的温度下限值时，电池给加热器供电使其工作，当水温达到温度设定上限值时，加热器断电，这样就可以将水温控制在一个使用温度范围内。为考虑方便节能，充电模块主要研究无线充电和太阳能充电设计。

Abstract：Water is the physiological element that all life process can carry on normally，man is inseparable from water. Drinking water management is particularly important for people and for infants and young children. The water content and metabolic rate in the child's body are higher，the ability of kidney withering is limited，and it is more prone to water deficiency or deficiency.By using AT89C51 single chip microcomputer and peripheral circuit as the control core to complete the monitoring and control of water temperature. The inner part of the cup is equipped with a solar panel charging device，which can charge the inner battery (normal USB socket can also charge it)；the inner part of the cup is measured by DS18B20 temperature sensor，the cup shell is equipped with a LED display screen，which shows the temperature inside the cup and the set temperature. Power supply makes it work，when the water temperature reaches the upper limit of temperature setting，the heater is cut off，so that the water temperature can be controlled in a range of operating temperature. In order to consider the convenience and energy saving，the charging module mainly studies the design of wireless charging and solar charging.
