ZL50装载机驱动桥设计

摘要

本次设计内容为ZL50装载机驱动桥设计，大致上分为主传动的设计，差速器的设计，半轴的设计，最终传动的设计四大部分。其中主传动锥齿轮采用35 56506 .螺旋锥齿轮，这种类型的齿轮的基本参数和几何参数的计算是本次设计的重点所在。将齿轮的几个基本参数，如齿数，模数，从动齿轮的分度圆直径等确定以后，用大量的公式可计算出齿轮的所有几何参数，进而进行齿轮的受力分析和强度校核。了解了差速器，半轴和最终传动的结构和工作原理以后，结合设计要求，合理选择它们的形式及尺寸。本次设计差速器齿轮选用直齿圆锥齿轮，半轴采用全浮式，最终传动采用单行星排减速形式。

关键词：ZL50装载机；中央传动；轮边减速器；

ZL50 loader driving axle design

Abstract

The design of content-driven ZL50 loader bridge design, largely at the main transmission design, the differential design ,Half-shaft design, the design of the final drive four majority.Including the main drive bevel gear used 35o bevel gears, This type of gear and the basic parameters of the geometric parameters of this design is the key point. Gear will be a few basic parameters, such as number of teeth, module, the sub-driven gear circle diameter determined,spent a lot of formula to work out all the gear geometric parameters, and then gear for the Analysis and strength check. Understand the differential, and the final drive axis of the structure and working principle, the combination of design requirements, They reasonable choice of the form and size. The design differential gear selection straight bevel gears, axis-wide floating, and ultimately drive single row slowdown planets form.
