摘 要

随着国内外市场对水果和蔬菜需求量的增加，人民生活水平的提高，越来越多的人对番茄制品有了更多的要求。番茄产品多元化的发展给水果和蔬菜加工带来了难得机遇，抓住机遇，加快对水果和蔬菜加工关键技术及设备的研究。基于该课题背景，回顾两年所学知识，对所学的专业知识进行整合。通过论述与研究果蔬机械产业的现状和发展，结合发展的实际要求而设计出可以将果蔬的清洗和打浆一块进行的设备。主要针对该设备的清洗和打浆两部分的机械结构的设计以及传动系统的设计。具体进行了包括设备的总体设计，清洗机架结构的设计，辊筒结构的设计，打浆机架的结构设计，打浆的结构设计，打浆机构固定的设计，传动系统的设计等，在同一时间完成设备的三维建模及主要零件的计算。

关键词：清洗打浆机、三维造型、传动系统、结构设计

Abstract

As the domestic and international market demand of fruits and vegetables, and the improvement of people's living standards, more and more people have more request for tomato products. Tomato products diversified development has brought the fruit and vegetable processing of the rare opportunity, seize the opportunity to speed up the fruit and vegetable processing key technology and equipment research. Based on the background of the subject , mechanical engineering and automation professionals to integrate the knowledge and runs through knowledge learned in the past two years. Through discussion and research status and development of fruit and vegetable machinery industry, combined with the actual requirements of the development and design of the device can be a piece of fruit and vegetable cleaning and beating carried out. Focusing on one machine washing, beating the two part of the mechanical structure and the transmission system design. Concrete was one of machine design, cleaning machine structure design, roller structure design, beating frame structure design, the structure design of beating, beating mechanism is fixed in the design, the transmission system design. At the same time on the machine for 3D modeling and the main parts of the check.

Keywords: Beater washing machine, 3D modeling, transmission system, structural design
